Simplex Meal Delivery Robot

This indoor autonomous mobile robot is a Food Delivery Robot Solution integrating food delivery, advertising marketing and welcome interaction. It is applicable to indoor scenarios including restaurants, hotels and office buildings for automatic goods delivery. It features 3D full-coverage obstacle avoidance, 4-layer modular tray, LiDAR SLAM autonomous navigation, IoT cross-device linkage and cloud multi-robot scheduling.

Product Adventage

Robot Tasks

The robot can perform food serving, empty tray recycling, material delivery, fixed-point patrol greeting and in-store advertising. It supports multiple operation modes: direct single-point delivery, multi-point batch delivery, designated tray delivery and cyclic patrol. It also supports table call and remote call to complete pick-up and delivery tasks.

Common Workflow

Staff place meals on the robot's tray in the kitchen → Select target tables via backend or tablet → The robot autonomously plans the path and travels to the designated position → Remind customers to collect food by light and voice prompts. After food pickup, it can receive a tray return command to carry empty tableware back to the kitchen. It can also run on a preset cyclic patrol route for greeting guests and playing advertisements.

Applicable Environment & Limitations

Applicable: Indoor floors including tiles, wooden floors, carpets and gentle ramps. Suitable for commercial environments with heavy foot traffic and relatively narrow aisles.
Limitations: For indoor use only. Keep away from permanently waterlogged areas. Max climbing gradient: 10°, max obstacle crossing height: 20 mm. It cannot travel if exceeding these parameters.

3D Omnidirectional Autonomous Navigation, Positioning & Blind-Spot-Free Obstacle Avoidance

Benefits: Restaurants and hotels have heavy pedestrian flow with tables, chairs, people's legs and suspended clutter everywhere. The robot can detect low and suspended obstacles, reducing jamming and collisions to guarantee stable operation during peak hours. No QR codes need to be pasted on the floor, lowering site renovation costs.

Four-layer Modular Smart Induction Tray

Benefits: The four-layer tray can carry meals for multiple tables at the same time and support one-off multi-point delivery. Equipped with load sensing and AI light strip status reminder, it helps attendants quickly check whether there are meals on the tray. The tray is quick-detachable, allowing flexible adjustment of layers to adapt to different delivered items.

Cloud-based Multi-robot Scheduling, Remote Mapping & Automatic Task Management

Benefits: Multiple robots can work simultaneously with tasks automatically assigned to avoid channel congestion. It supports remote mapping completed within minutes, so no on-site engineer deployment is required, cutting the go-live time. Automatic charging is also available.

Product Parameters

General	Dimensions	580 × 490 × 1290 mm
	Net Weight	/ kg
	Touch Screen	10.1" 1280 × 720 resolution
	Advertising Screen	15.6" 1920 × 1080 resolution
	Climbing ability	10°
	Movement speed	0.3~1.2 m/s
	Passage width	650 mm
Load Capacity	Load Layout	4 trays, 430 × 400mm
	Load per Tray	10 kg
	Total Load Capacity	40 kg
Battery Life	Battery Type	15Ah
	Working Endurance	10 h
	Chargin Endurance	3 h
Accessories	Optional Accessories	Charging station,Return box
